Needle Connector Series
Needle header connector is a common electrical connector, widely used in various electronic devices. They usually consist of multiple metal pins (pins) and corresponding sockets to achieve the connection of electrical signals and power.
High reliability:
The pin header connector is precisely designed to ensure stable electrical contact, reduce contact resistance, and ensure signal integrity.
Easy to connect and disassemble:
The design is convenient and can be quickly plugged and unplugged, suitable for equipment that needs to be frequently replaced or repaired.
Diverse specifications:
A variety of pin numbers, pitches and forms are available to meet different equipment and connection requirements.
Durability:
Usually high-strength materials are used, with good wear resistance and corrosion resistance, and adapt to various working environments.
Anti-misplugging design:
Some pin header connectors adopt anti-misplugging design to ensure the correct direction when connecting and prevent damage caused by misplugging.
Application scenarios
Automotive electronics:
Used for the connection of on-board electronic devices such as audio systems, navigation systems, control units, etc.
Consumer electronics:
Used for the connection of internal circuits in mobile phones, tablets, TVs and other devices.
Industrial equipment:
Widely used in industrial automation equipment and control systems to connect sensors, actuators and controllers.
Communication equipment:
In network equipment, switches and routers, it is used to achieve signal transmission and power connection.
Installation and maintenance
Correct connection:
Ensure the direction and position of the header connector during installation to avoid poor contact caused by wrong insertion.
Regular inspection:
Regularly check the wear of the connector to ensure that there is no damage, aging or deformation to maintain a good electrical connection.
Cleaning and maintenance:
Regularly clean the connector contact surface to avoid dust and dirt affecting signal transmission.
Summary
The header connector is an indispensable and important component in electronic devices, providing stable electrical connection and signal transmission. Its flexible and diverse design is suitable for various industries and applications, and is an ideal choice for achieving electrical connection.
Rated voltage: Usually between 30V and 250V, depending on the design and application of the connector.
Rated current: Usually between 1A and 20A, depending on the design and purpose of the pin.
Operating temperature range: -40°C to +105°C, adapting to a variety of working environments.
Pin material: Generally copper or gold-plated materials are used to ensure good conductivity.
