SMB Camera Harness
SMB camera harness is a cable assembly designed for camera systems, especially for applications that require high-frequency signal transmission, such as automotive electronics, security monitoring and industrial equipment. SMB connectors are widely used in a variety of occasions due to their good electrical performance and reliability.
1. Product Features
High-frequency performance:
SMB connectors are designed for high-frequency signal transmission, with low insertion loss and high return loss to ensure signal integrity and stability.
Strong anti-interference ability:
The harness adopts a shielded design to effectively resist electromagnetic interference (EMI) and maintain good signal transmission in complex electrical environments.
Durability:
The cables and connectors are made of high-quality materials with excellent wear resistance, corrosion resistance and high temperature resistance, and are suitable for various environmental conditions.
Convenient installation:
The plug-in design of the SMB connector makes installation and maintenance more convenient and suitable for devices with limited space.
Diverse choices:
A variety of lengths and connector types are available to meet the needs of different applications.
2. Technical parameters
Rated voltage: Typically 50V, depending on the use environment and system requirements.
Rated current: Typically 1A to 3A, suitable for low-power devices.
Operating frequency range: It can support signal transmission up to 4GHz, suitable for high-definition image and video signals.
Operating temperature range: -40°C to +85°C, adapting to different environmental conditions.
Connector type: SMB connector, with a good lock design to ensure stable connection.
3. Application scenarios
Automotive camera system:
In applications such as car reversing images, 360-degree surround view, ADAS (Advanced Driver Assistance System), etc., SMB camera harnesses are used to connect cameras and on-board electronic control units to provide high-definition signal transmission.
Security monitoring equipment:
In surveillance cameras, SMB harnesses are used to connect cameras and recording equipment to ensure the stability and clarity of video signals.
Industrial automation:
Used in industrial cameras and machine vision systems, connecting cameras and control units to achieve real-time image transmission and processing.
Medical equipment:
In medical imaging equipment, SMB harnesses are used to connect image sensors and display systems to ensure the transmission of high-quality images.
4. Installation and maintenance
Correct connection:
During installation, ensure that the SMB connector is firmly connected to avoid signal interruption due to vibration or improper operation.
Regular inspection:
Regularly check the wear of the harness and connector to ensure that there is no aging or breakage to maintain the reliability of signal transmission.
Waterproof and dustproof: For exposed connectors, ensure good waterproof and dustproof design to prevent the intrusion of moisture and dust.
Summary
SMB camera harnesses play a key role in a variety of industries, ensuring efficient connection and signal transmission between cameras and other devices. Its excellent anti-interference performance, durability and flexibility make it an ideal choice for automotive electronics, security monitoring and industrial automation.
